LTI-EB Engines & gearboxes breaker machine

For details, information, price offers and orders please contact us.

  • Engines and gear boxes breaker with double magnetic separator system
  • Model: LTI-EB
  • Capacity: 3.5 – 5.0 T / H (depending the feeding way)
  • Machine dimensions: 3.340x 1545 x 2.922 mm LxWxH minimum
  • Machine weight: 10.000 T minimum
  • Charging box dimensions: 1080 x 980 mm minimum
  • Hopper dimensions: 1500×980 mm minimum
  • Compression Force: up to 135 T
  • Resulted material dimension’s after breaking of engines and gear boxes: down to 4 cm x 4 cm **
  • Electric Engine: minimum 30 KW (in base of model will be 1 / 2 engines – 20+11KW)
  • Electrical panel heating system for winter: – Included in the price
  • Remote control: Optional and not in the price – Optional and extra cost
  • Oil Cooling system: Included in the price
  • Oil Heating system for winter: Included in the price
  • Electrical system / components: Telemecanique / Simens / Schinder
  • Power supply: Electric engine / motor electric
  • PLC: Simens Brand
  • Hydraulic system Brands: Parker / Rexroth-Bosh
  • Hydraulic pumps: Parker
  • Compression and crushing chamber – interior wear plates: Hardox 450
  • Output Conveyor belt and magnetic separation conveyor: Optional and extra cost – not included in the standard selling price
  • Magnetic separation system: from 85 till 99.9% iron separation from Al
  • Maximum operation force: 245 bars
  • Fast: Minimum 25 seconds dry cycle time and 1.45 minutes crushing time
  • Comments: The machine dimensions and weight could change in base of customer wastes types and dimension and customer request
  • The engine crusher is designed to process personal vehicles / car engines, gearboxes and aluminum wheels. PKW engines
  • The machine has a pusher cylinder with 135 tons crushing force. – – The entire box of the machine is equipped with HARDOX wear plates.
  • Due to a sophisticated system you are able to adjust the opening of the exit, determining the size of the output material
  • By crushing the engines and gear boxes you are able to easily separate the valuable aluminum from the steel.
  • This machine is designed to work in fully automatic cycle after the loading hopper is filled.

  • We design and produce engines and gearboxes breakers different models and machine dimensions in base of customer wastes types, wastes dimensions and customer request / needs.
  • Like extra option and price we offer double magnetic separation of iron from aluminum.
  • Beside the engine cracking function we also can deliver on the same machine also the balling function like extra option (not included in the standard version and price)
  • For more information’s, technical price offers and orders please contact us
